ESD Safe PETG
Technology:
For use in critical applications that require electrostatic discharge (ESD) protection.
ESD Safe
PETG-ESD offers electrostatic discharge (ESD) safety with improved toughness making it a good candidate for applications in electronics industry.
Ideal Size ≤
600 x 600 x 600 mm
(24 x 24 x 24 in)
Resolution
0.16 - 0.4 mm
Colors
Black
Economical
Max Size
Flexibility
Strength
Heat Resistance
Economical
Label
Max Size
Label
Flexibility
Label
Strength
Label
Heat Resistance
Label
Compare with other
FDM
materials
Material
Economical
Max Size
Flexibility
Strength
Heat Resistance
Specifications
Mechanical Properties
(XY) Tensile Modulus
1983 ± 66 MPa
ISO 527, GB/T 1040
(XY) Tensile Modulus
1983 ± 66 MPa
ISO 527, GB/T 1040
(XY) Tensile Strength
36.1 ± 0.7 MPa
ISO 527, GB/T 1040
(XY) Tensile Strength
36.1 ± 0.7 MPa
ISO 527, GB/T 1040
(XY) Elongation at Break
7.3 ± 0.5 %
ISO 527, GB/T 1040
(XY) Elongation at Break
7.3 ± 0.5 %
ISO 527, GB/T 1040
(XY) Bending Modulus
1658 ± 164 MPa
ISO 178, GB/T 9341
(XY) Bending Modulus
1658 ± 164 MPa
ISO 178, GB/T 9341
(XY) Bending Strength
54.0 ± 3.0 MPa
ISO 178, GB/T 9341
(XY) Bending Strength
54.0 ± 3.0 MPa
ISO 178, GB/T 9341
(XY) Charpy Impact Strength
5.7 ± 0.6 kJ/m2
ISO 179, GB/T 1043
(XY) Charpy Impact Strength
5.7 ± 0.6 kJ/m2
ISO 179, GB/T 1043
Thermal Properties
Glass Transition Temperature
77 °C
DSC 10°C/min
Glass Transition Temperature
77 °C
DSC 10°C/min
Decomposition Temperature
373 °C
TGA 20°C/min
Decomposition Temperature
373 °C
TGA 20°C/min
Vicat Softening Temperature
86 °C
ISO 306, GB/T 1633
Vicat Softening Temperature
86 °C
ISO 306, GB/T 1633
Heat Deflection Temperature (1.8MPa)
72 °C
ISO 75, 1.8MPa
Heat Deflection Temperature (1.8MPa)
72 °C
ISO 75, 1.8MPa
Heat Deflection Temperature (0.45MPa)
76 °C
ISO 75, 0.45MPa
Heat Deflection Temperature (0.45MPa)
76 °C
ISO 75, 0.45MPa
Chemical Resistance
Weak Acids
Good
Weak Acids
Good
Strong Acids
Fair-Poor
Strong Acids
Fair-Poor
Weak Alkalis
Poor
Weak Alkalis
Poor
Strong Alkalis
Poor
Strong Alkalis
Poor
Oils and Grease
Good
Oils and Grease
Good
