ASA
Technology:
ASA is a durable, UV-resistant 3D printing material ideal for outdoor applications and long-lasting parts.
Strong
High Temperature
Weather Resistant
Impact Resistant
ASA (Acrylonitrile Styrene Acrylate) is a high-performance material designed for exceptional durability and UV resistance. Ideal for outdoor applications, ASA parts boast excellent weatherability, retaining mechanical properties and appearance even when exposed to harsh elements.
Ideal Size ≤
256 x 256 x 256 mm
(10 x 10 x 10 in)
Resolution
0.16 - 0.4 mm
Colors
Black
White
Grey
Red
Blue
Economical
Max Size
Flexibility
Strength
Heat Resistance
Economical
Label
Max Size
Label
Flexibility
Label
Strength
Label
Heat Resistance
Label
Compare with other
FDM
materials
Material
Economical
Max Size
Flexibility
Strength
Heat Resistance
Specifications
Mechanical Properties
(XY) Tensile Modulus
2174.6 ± 41.1 MPa
ISO 527, GB/T 1040
(XY) Tensile Modulus
2174.6 ± 41.1 MPa
ISO 527, GB/T 1040
(XY) Tensile Strength
38.6 ± 0.3 MPa
ISO 527, GB/T 1040
(XY) Tensile Strength
38.6 ± 0.3 MPa
ISO 527, GB/T 1040
(XY) Elongation at Break
4.4 ± 1.0 %
ISO 527, GB/T 1040
(XY) Elongation at Break
4.4 ± 1.0 %
ISO 527, GB/T 1040
(XY) Bending Modulus
1939.7 ± 50.4 MPa
ISO 178, GB/T 9341
(XY) Bending Modulus
1939.7 ± 50.4 MPa
ISO 178, GB/T 9341
(XY) Bending Strength
60.9 ± 0.9 MPa
ISO 178, GB/T 9341
(XY) Bending Strength
60.9 ± 0.9 MPa
ISO 178, GB/T 9341
(XY) Charpy Impact Strength
10.5 ± 0.6 kJ/m2
ISO 179, GB/T 1043
(XY) Charpy Impact Strength
10.5 ± 0.6 kJ/m2
ISO 179, GB/T 1043
Thermal Properties
Glass Transition Temperature
97.8 °C
DSC 10°C/min
Glass Transition Temperature
97.8 °C
DSC 10°C/min
Vicat Softening Temperature
105.3 °C
ISO 306, GB/T 1633
Vicat Softening Temperature
105.3 °C
ISO 306, GB/T 1633
Heat Deflection Temperature (1.8MPa)
100.2 °C
ISO 75, 1.8MPa
Heat Deflection Temperature (1.8MPa)
100.2 °C
ISO 75, 1.8MPa
Heat Deflection Temperature (0.45MPa)
102.6 °C
ISO 75, 0.45MPa
Heat Deflection Temperature (0.45MPa)
102.6 °C
ISO 75, 0.45MPa
Chemical Resistance
Weak Acids
Resistant
Weak Acids
Resistant
Strong Acids
Slightly resistant
Strong Acids
Slightly resistant
Weak Alkalis
Resistant
Weak Alkalis
Resistant
Strong Alkalis
Slightly resistant
Strong Alkalis
Slightly resistant
Organic Solvent
Not resistant
Organic Solvent
Not resistant
Oils and Grease
Resistant
Oils and Grease
Resistant
Equilibrium Water Absorption
0.4%
Equilibrium Water Absorption
0.4%
